Product information

Standards & Approvals

CE approved, SS-EN 33 dimensioning and SS-EN 997 function

Specifications Product datasheet PDF with product image BIM-3D (.3ds/.jpg/.max/.dwg/.gsm/.rfa) Declaration of performance Product image Flow diagram Additional info Read more about Hygienic Flush
Read users´ reviews

Assembling & Care

Floor mounting with four stainless steel screws and plastic caps. The rounded cistern and the small outer dimensions makes it suitable for corner installations. Intended primarily as a replacement model during renovation without stack and/or floor replacement. The large footprint covers marks left on the floor by the old toilet. Please refer to the installation manual. Fittings included.

Drawing Assembly instruction Care instruction

Other info

Ballcock with adjustable connection R1/2´ exterior metal threads. The bottom valve has a button-operated half and full flush (dual flush). Factory set to 2.6/4.0L, or with a button-operated bottom valve for single flush set for 4 or 6 litres.

Deep -

Length -

Width -

Features

Made from hygienic, durable and densely sintered sanitary wareEasy-to-clean and minimalistic design
Glazed under the flush edge for simplified cleaning
Factory set single flush 6L
Elevated seat height compared to other models, 460mm
The large footprint covers marks left by old toilet
Full-coverage, condensation-free cistern
Quiet refilling
Can be combined with armrest and care seat for improved accessibility
Several seat options in two different colours, white or black
With open, glazed flush edge for simplified cleaning
Flushes all the way up to the rim for improved hygiene
Adjustable water connection R1/2´ for flexible installation
Mounting to floor with four screws or adhesive installation
Suitable for corner installation
