Shower mixer Care

Shower mixer Care

  • RSK-nr: |
  • ART-nr: GB41202314660 |
  • EAN-nr: 7391530086811
Thermostat, drain valve, hose, hand shower
  • Developed according to "Guidelines for healthcare hygiene aspects"
  • Safe Touch reduces the heat on the front of the faucet
  • Drainage valve empties the water to minimise risk of legionella
Lead_free Safe_touch Smart_inside Even_temperature_detailed
Product information Product information Find dealers Other options of same product Acessories and assembly products Other interesting products Find dealers

Product information

Standards & Approvals
Specifications Product datasheet PDF with product image Product image Flow diagram
Assembling & Care

Prior to installation the lines must be flushed up to the faucet. The faucet is connected with the cold water line on the right and the hot water line on the left. Water pressure: max 1000 kPa, min 50kPa. Hot water temperature: max 70°C, min 45°C. Please note that we are not liable for damage resulting from improper installation.

Drawing Assembly instruction
Other info
Deep - 75 mm
Length - 295 mm
Width - 285 mm
Max. tap capacity (at 300 kPa): 0,425 l/s
Pressure loss with flow (0,33 l/s) 181 kPa
Features
  • Contains less than 0.1% lead
  • Developed according to "Guidelines for healthcare hygiene aspects"
  • Safe Touch reduces the heat on the front of the faucet
  • Drainage valve empties the water to minimise risk of legionella
  • With functionally adapted grip-friendly knobs
  • Built-in automatic hot water block for scald protection
  • Built-in automatic hot water block for scald protection
  • Adjustable max temperature for increased scald protection
  • Ceramic cartridge ensures non-drip operation and longevity, in addition the use for small and weak hands is simplified
  • Drainage valve empties the hand shower and shower hose of residual water to minimise risk of legionella
  • Type-approved check valve in the inlet
  • Backflow protection in accordance with SS-EN 1717 [EB]
