Dušisegisti New Nautic

Dušisegisti New Nautic

  • Alias number: |
  • Tootenumber: GB41202014 |
  • EAN number: 7391530081830
Dušiühendus alla, 160 c-c
  • Grip-friendly lever with clear color marking for hot and cold
  • Soft move, ceramic package with smooth and precise handling
  • Eco-Stop, adjustable maximum flow limitation
Tooteinfo Tooteinfo Leia edasimüüja Teised sarnased tooted Lisatarvikud ja kinnitusdetailid Muud huvitavad tooted Leia edasimüüja

Tooteinfo

Vastavustunnistused
Tehnilised andmed Tooteleht PDF with product image Tootepilt Vooluhulga graafik
Paigaldus ja hooldus

Enne paigaldamist tuleb torude loputamiseks lasta veel joosta. Segisti on ühendatud paremalt külmaveetoruga ja vasakult kuumaveetoruga. Veesurve: max 1000 kPa, min 50 kPa. Kuuma vee temperatuur: max 80 °C, min 45 °C. Me ei vastuta valest paigaldusest tuleneva kahju eest.

Joonis Paigaldusjuhendid
Muu info
Sügavus - 90 mm
Kõrgus - 192 mm
Laius - 143 mm
Max. tap capacity (at 300 kPa): 0,37 l/s
Pressure loss with flow (0,1 l/s) 22 kPa
Omadused
  • Easy grip lever with clear colour marking for hot and cold
  • Soft move, ceramic package with smooth and precise handling
  • Eco-Stop, adjustable maximum flow
  • Adjustable max temperature for increased scald protection
  • Ceramic cartridge ensures non-drip operation and longevity
  • Type-approved non-return valves in the inlet
  • Backflow protection in accordance with SS-EN 1717 [EB]
  • Can be functionally adapted with extended lever
